Mechanical Seals |
| |
Product Name |
Product Description |
Product View
(Click on Image to Enlarge) |
| Single Spring |
Series - 1:
These seals are designed to handle abrasive, slurry,
sludge, sewage and viscous fluid
which is very easy installed, Different seal faces and materail available according
to applications.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
| 130 |
-17°C to 204°C |
10bar |
26 m/s |
| 131 |
-23°C to250°C |
10bar |
26 m/s |
| 170 |
-17°C to 204°C |
35bar |
26 m/s |
| 171 |
-23°C to 250°C |
35bar |
26 m/s |
Equivalents to :-
John Crane - 209, 209B, Sealol-Series - 1500,
Dura - ARO, ARO - TT, APTO, APT Burgmann H76 and similar.
|
Single Spring
|
| Multi Spring |
Series - 2 :
These seals having compact
design, with interchangeable parts. Hence low cost
easy in maintenance & installation. Different seal
faces & materail are available according to applications.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
230
|
-17°C to 204°C |
10bar |
26 m/s |
| 231 |
-23°C to 250°C |
10bar |
26 m/s |
270
|
-17°C to 204°C |
35bar |
26 m/s |
| 271 |
-23°C to 250°C |
35bar |
26 m/s |
Equivalents to :-
John Crane - 58U, 58B, 59U, 59B,
Sealol - Series - 500, Burgman - M74 and similar.
|
Multi Spring
|
| PTFE Bellow |
Series - 3 :
These series are developed
to handle extremely corrosive liquids such as
acids and alkalies etc. These seals are mounted externally
with replaceable seal face. Different seal materials
are available according to applications.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
| 33S |
120°C |
6bar
|
20 m/s |
| 33R |
120°C |
6bar
|
20 m/s |
Equivalents to :-
John Crane - 20, 20R, Durra - TB, TBR
Sealol - 650, 652, Burgmann - TF.
|
PTFE Bellow
|
| Conical Spring |
Series - 4 :
These seals are designed in
single conical self-driving spring,
It is used for normal applications in gear pumps,
water pumps and mono block pumps.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
430
|
-23°C to 204°C |
10bar |
20 m/s |
| 470 |
-23°C to 204°C |
25bar |
20 m/s |
Equivalents to :-
Dura Metallic CRO, Burgmann M2 and M3 |
Conical Spring
|
| Rubber Bellow |
Series - 5:
These series having elastomer bellow, which
allows self alignment in shaft motion. It is very easy in
installation & maintenance and parts are interchangeable,
it is a low cost mechanical seal due to mass production.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
| 501, 512, 513 |
-17°C to 180 °C |
12bar |
20 m/s |
| 543 |
-17°C to180°C |
10bar |
20 m/s |
| 51,51A,52 |
-17°C to 180 °C |
35bar |
20 m/s |
| 56,56A |
-17°C to 180 °C |
5bar |
20 m/s |
Equivalents to :-
John Crane - 6, 6A, 1, 1A, 2, Sealol - 43, Burgmann - MG Series. |
Rubber Bellow
|
| Reverse Balance Seal |
Series - 6 :
These seals are designed to be external mounted
for hydraulic pressure balanced without Shaft - Step or Sleeve.
This seal is specially used for corrosive application because all
metallic components do Not come in contact with liquid to
be sealed.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
670
|
-23°C to 150 °C |
25bar |
20 m/s |
Equivalents to :-
Dura RA and similar. |
Reverse Balance Seal
|
| Metal Bellow Seal |
Series - 7:
These seal are ideal for high temperature
application. The welded metal bellow provide face load
under any operating conditions.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
| 770 |
-23°C to 204 °C |
14bar |
26 m/s |
| 770 / 771, 771 |
-45°C to350°C |
14bar |
26 m/s |
Equivalents to :-
John Crane - 15W, 15WV, 215,
Burgmann - MF Series, Dura Metallic - CBR, CBS, PBR, PBS |
Metal Bellow Seal
|
| Wave Spring |
Series - 8 :
These seals designed with wave spring to handle abrasive, slurries, sludes, sewage and viscous
fluid. Major advantage of this seal is that it is compact,
axial length but non sticking or clogging.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
| 830 |
-17°C to 204 °C |
10bar |
26 m/s |
| 831 |
-23°C to 250 °C |
10bar |
26 m/s |
| 870 |
-17°C to 204 °C |
35bar |
26 m/s |
| 871 |
-23°C to 250 °C |
35bar |
26 m/s |
Equivalents to :-
Burgmann M7 and similar. |
Wave Spring
|
| Cartridge Seal |
Series - 9:
These are heavy duty mechanical seals accurately designed and balanced independent in direction of shaft rotation. It is pre-assembled tested unit so that it is easy and reliable to be
mounted with no setting or alignment.
Operating Condition :-
| Type |
Temp.
|
Pressure |
Speed |
970
|
-23°C to 204 °C |
15bar |
20 m/s |
| 971 |
-15°C to 250°C |
25bar |
20 m/s |
|
Cartridge Seal
|
|
| |
|
| |
